1. Instructions for use

Application range of instrument:  YSB-DU10V have the leading image process technical and practical clinic solution method, apply to ultrasound diagnosis of Bovine, Equine, Camel, Canine, Feline, Goat, Ovine and Swine.

For examine of abdomen, heart, gynecology, obstetrics, urology, small organs, blood vessels, etc.

2. Main technical parameters and requirements:

2.1   Machine size, weight

Size: 400(L)*394(H)*172(W)

Weight: only unit 7.5kg, with one probe 8.2kg, with two probes 8.9kg.

2.2   Number of channels / array elements

2.3   Monitor

High resolution 15 "LCD display

2.4   ★Full Digital Imaging Technology

1.  Pulse inverse harmonic composite imaging

2. Multi-beam synthesis

3.  Space compound

4.  Image enhancement noise reduction

2.5   Imaging mode

1. B mode

2. M mode

3. Color (Color Doppler ) mode

4.  PDI (Energy Doppler)mode

5.  PW (Pulse Doppler)mode

2.6   Image display mode

B、2B、B+M、4B、M、B+Color、B+PDI、B+PW、B+Color+PW、B+PDI+PW、★B+C/PDI Double real time

2.7   Supported probes

1.   Convex probe

2.   Linear probe

3.   Cavity probe

4.   Micro-convex probe

2.8   Supported frequency

B/M: Third gear fundamental frequency + second gear harmonic frequency;

C：2 gear

PW:2 gear

2.9   ★Cine loop

1.   2D mode, B Maximum: ≥5000 frames, Color, PDI Maximum: ≥2500 frames;

2.    Timeline mode (M, PW), Maximum: ≥ 190s

2.10 Image zoom

Real-time scanning（B、B+C、2B、4B）Status: stepless enlargement

2.11 Image storage

1.       Support JPG, BMP, FRM image formats and CIN、AVI movie format

2.    Support local storage;

3.   ★Support  DICOM， meet the DICOM3.0 standard;

4.   ★Built-in workstations: Support large-capacity hard disk (≥500GB),support patient data retrieval and browsing.
